The LAUNCH™ TLT440 Hydraulic 4 Post Lift
With hydraulic cylinder and steel cable synchronization, the 4000KG load capacity lift TLT440 guarantees a stable and smooth lifting and lowering.
Two-layer concealed plate structure provides excellent synchronizing performance with the horizontal precision of 1mm.
As the first priority, safety has been considered from design to manufacture.
TLT440 is equipped with electric controlled lifting, cable rupture safety system and lowering and cylinder travel limit switch.
It is CE certificated.
Features for LAUNCH™ TLT440 Lift
Two-layer concealed plate structure, excellent synchronizing performance with the horizontal precision of 1mm.
Driven by hydraulic cylinder and steel cable synchronization makes stable lifting and lowering.
Full-range mechanical safety protection by using the safety latches, manual lowering operation.
Cylinder travel limit device effectively protects cylinder and extends its lifespan.
Cable rupture safety system ,effectively protects vehicle from overturn.
Electric controlled lifting and lowering type is optional.
Four connected steel cables force synchronized movement of the lift, effectively prevent vehicles from sloping.
Distance between two platforms is adjustable for the vehicles with different wheel track .
Passed national standards and CE certificated.
Technical Specifications
Rated Load | 4000kg |
Lifting Height | 1850mm |
Initial Height | 170mm |
Lifting Time | ≤60s |
Lowering Time | ≥20s, ≤40s |
Max. Drive-on Width | 3045mm |
Platform Length | 4240mm |
Platform Width | 500mm |
Overall Width | 3445mm |
Overall Height | 2172mm |
Motor Power | 2. 2kW |
Motor Voltage | 3 phase/380v or Single phase/220V |
Working Noise | ≤75dB(A) |
Working Oil Pressure | 16MPa |
Working Air Pressure | 0.5~0.7MPa |
Important Notes:
- Price does not include delivery.
- Installation costs are extra and lift bases must meet minimum spec.
- Customer must prep own floor to spec and supply electricity, single phase.
- If 3-phase power system is required, contact us first before order.
