The LAUNCH™ TLT240SC
With double hydraulic cylinders and high strength chain drive, the 4000KG load capacity two post lift TLT240SC guarantees a stable and smooth lifting and lowering. Its patented slider bracket design improves the replacing efficiency.
As the first priority, safety has been considered from design to manufacture. TLT240SC is equipped with bilateral manual safety unlocking system, 24V low voltage control box and cylinder travel limit switch. It is CE certificated.
Features for LAUNCH™ TLT240SC Lift
Bilateral manual safety unlocking system.
The cable and oil pipe are fully concealed; with decent and elegant appearance.
Double hydraulic cylinder and high strength chain drive makes stable and smooth lifting and lowering.
Wire rope equalization system forces synchronous movement of two carriages and effectively prevents vehicle from tilting.
24V low voltage control box（IP54 level）ensures operator’s safety.
24V cylinder travel limit switch effectively protects cylinder and extends its lifespan.
Door rubber pad protects car door from being damaged in collision.
More lifting pads with different height meets the requirements for light lorries and SUVs.
Passed 115% dynamic loading test and 150% static loading test .
CE certificated.
Symmetric and asymmetric installation types are optional. (For SC model).
Technical Specifications
Rated Load | 4000kg |
Lifting Height | 1850mm |
Initial Height | 110mm |
Lifting Time | ≤50s |
Lowering Time | ≥20s, ≤40s |
Passing Width | 2486mm |
Overall Width | 3370mm |
Overall Height | 2860mm |
Motor Power | 2.2kW |
Motor Voltage | 3 phase/380V or Single phase/220V |
Working Noise | ≤75dB(A) |
Working Oil Pressure | 16MPa |
Important Notes:
- Price does not include delivery.
- Installation costs are extra and lift bases must meet minimum spec.
- Customer must prep own floor to spec and supply electricity, single phase.
- If 3-phase power system is required, contact us first before order.
